5977T 1/2 × 1/2 4FL RUFF
SQ End Mill; 1/2″ Dia. × 1-1/4″ LOC × 1/2″ Shank Dia. × 3″ OAL ; 0.025″ RE ; 0.025″ RE ; 4 FL ; 1-1/4″ LBS ; Carbide ; AlTiN ; Series 5977T
| Cutting Diameter (DC) | 1/2″ | Corner Radius (RE) | 0.025″ |
| Connection Diameter Machine Side (DCONMS) | 1/2″ | Tool Type | Single End |
| Depth of Cut Maximum (APMX) | 1-1/4″ | Length Group | Regular |
| Overall Length (OAL) | 3″ | Flute Type | Medium Pitch |
| Cutting Edge Material | Carbide | Coolant Supply Property (CSP) | External |
| Coating | AlTiN | Style | Roughing |
| Flute Count (NOF) | 4 | Decimal Equivalent | 0.5″ |
| Shank Type | Round | Measurement Type | Inch |
| End Shape | Corner Radius | Series/List # | 5977T |
| Usable Length (LU) | 1-1/4″ | Corner Radius (RE) / Chamfer Width (CHW) | 0.025″ |
| Application | Roughing |
Product Features
| Country of Origin | USA |
Shipping Info
Package Weight
0.33
