5954G 1/4 × 1/4 2FL SE
SQ End Mill; 1/4″ Dia. × 1-1/8″ LOC × 1/4″ Shank Dia. × 3″ OAL ; 2 FL ; 1-1/8″ LBS ; Carbide ; TiN ; Series 5954G
| Cutting Diameter (DC) | 1/4″ | Usable Length (LU) | 1-1/8″ |
| Connection Diameter Machine Side (DCONMS) | 1/4″ | Application | Finishing |
| Depth of Cut Maximum (APMX) | 1-1/8″ | Tool Type | Single End |
| Overall Length (OAL) | 3″ | Length Group | Long |
| Cutting Edge Material | Carbide | Coolant Supply Property (CSP) | External |
| Coating | TiN | Style | Finishing |
| Flute Count (NOF) | 2 | Decimal Equivalent | 0.250″ |
| Flute Helix Angle (FHA) | 30 Degrees | Measurement Type | Inch |
| Shank Type | Round | Series/List # | 5954G |
| End Shape | Square |
Product Features
| Remarks | •Solid Carbide 2-Flute Single End Mills •TiN Coated Long Length | Country of Origin | USA |
Shipping Info
Package Length
3.12500
Package Width
.37500
Package Weight
0.075
